Features：
• Low quantum defect,Long fluorescence lifetime;
• Wide optical transmission range, from 0.12um to 10μm;
• Low dispersion behavior;
• Limited nonlinear effects under intense laser irradiation;
• Customized coatings are available.
Specification
| Concentration tolerance (ATM%) | 0.5 mol % ~ 30 mol % |
| orientation | [111] or [100] < ±0.5° |
| orientation tolerances | < 0.5° |
| Parallelism | 10〞 |
| Verticality | 15ˊ |
| surface quality | 10-5(MIL-O-13830A) |
| Wavefront distortion | <λ/8 @632 nm |
| Surface flatness | <λ/8 @632 nm |
| Luminous aperture | >90% |
| Chamfer | <0.1×45° |
| Thickness/diameter tolerance | ±0.05 mm |
| Maximum size | 2*2-15*15 mm×20mm |
| Thermal shock resistance parameters | 800 W/m |
| coating | AR≤ 0.2% @1030nm |
| Crystal Structure | Cubic |
| Lattice Constant | 5.462 Å |
| Density | 3.18 g/cm3 |
| Melting Point | 1418°C |
| Thermal Conductivity / (w · M-1 · K-1 @ 25 ° C) | 9.71 |
| Specific Heat Capacity / (j · G-1 · K-1) | 0.8876 |
| Thermo Optic Coefficient (dn / Dt) | −11.3 |
| Thermal Expansion / (10-6 · K-1 @ 25 ° C) | 19 |
| Hardness (mohs) | 4 |
| Young's Modulus / Gpa | 146 |
| Tensile Strength / Gpa | 2 |
