BaF2 Optical Window Barium Fluoride Optical Window

BaF2 Optical Window Barium Fluoride Optical Window has good transmittance in the wavelength range of 130nm-9500nm, with a transmittance of nearly 90%, and the refractive index changes little in a wide wavelength range.

0.0 (0 Reviews)

~~$10.00~~ $1.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Description

BaF2 Optical Window Barium Fluoride Optical Window
Barium fluoride crystal has good transmittance in the wavelength range of 130nm-9500nm, with a transmittance of nearly 90%, and the refractive index changes little in a wide wavelength range. It is usually applied to lenses, beam splitters, prisms, and windows in cryogenic imaging systems, aerospace optical systems, and laser optical systems.

Barium fluoride (BaF2) window has wide bandwidth transmittance and can transmit from far ultraviolet to long-wave infrared. Therefore, this product can be used in various applications, such as infrared spectroscopes. The low refractive index of barium fluoride is 1.48, which can provide high transmittance without antireflection film. In a dry environment, barium fluoride window sheets can withstand ambient temperatures up to 800 °, but prolonged contact with water will reduce the transmittance in the vacuum ultraviolet range. However, compared with the calcium fluoride window, the barium fluoride window has lower resistance to water. BaF2 window is an optical fluoride that can resist high-energy radiation but has lower UV transmission. BaF2 has a Knoop hardness of 82.

Specification

Technical Requirement	Commercial Grade	Precision Grade	High Precision Level
Size Range	1-600mm	2-600mm	2-600mm
Diameter Tolerance	土0.1mm	土0.025mm	土0.01mm
Thickness Tolerance	土0.1mm	土0.025mm	土0.01mm
Parallel Deviation	±3´	±15´´	±5´´
Surface Quality	60-40	40-20	10月20日
Surface Accuracy	1.0λ	λ/10	λ/20
Inverted Edge	0.1-0.5mm*45°
Material Science	Barium Fluoride(BaF2)

Standard Size

Diameter	Thickness mm	Coating requirements
10mm	1mm	Coating requirements can be customized according to customer requirements
12.5mm	1mm
20mm	2mm
25mm	3mm
30mm	3mm
38.1mm	3mm
40mm	4mm
50mm	3mm
50.8mm	3mm
63.5mm	5mm
75mm	3mm
75mm	5mm
76.2mm	6mm
80mm	8mm
90mm	10mm
100mm	10mm
150mm	15mm
180mm	18mm
200mm	20mm
300mm	35mm

Properties

Transmission wavelength range	150nm—12500nm
density (g cm-3)	4.89
melting point (℃)	1280
Dielectric constant	7.33 @ 2MHZ
Coefficient of thermal expansion (1/℃)	1.81*10-6@-100----+200
Body elastic modulus (Gpa)	56.4
Shear mode (Gpa)	25.4
Thermal conductivity (J/k .m. s)	11.72 @ 286k
Heat capacity (J/g .k)	0.410 @300k
Knoop hardness (kg/mm2)	82
Apparent elastic limit (Mpa)	26.89
Young's modulus (Gpa)	53.07
Poisson's ratio	0.343
Band gap (EV)	26.89
Water solubility (g / L)	1.7
density (g cm-3)	4.89
melting point (℃)	1280
